DT
BOND STRAP & WIRE
The grounding wire is composed of a joint and a copper braided wire;
The ground wire is a return line of current. The power comes out from the positive pole and then returns to the negative pole through a return line, forming a loop.
-
1
2
3 M8620-1130150
4 188
5 145
-
1
2 15mm2
3 M63Q1-3724200
4 310±2
5 2-Ø6.5
-
1
2 25mm2
3 M63H1-3724200
4 450±20
5 2-Ø6.5
-
1
2 90mm2
3 J41F1-3708200
4 500±2
5 Ø9 Ø13
-
1
2 25mm2
3 B3221-3708020
4 350±2
5 Ø9 Ø13
-
1
2 25mm2
3 670A-3708020
4 400±2
5 2-Ø10.5
